Human Presence Detector HET100

The HET100 human presence detector based on IR principle, is widely used to detect the presence of persons in the room, not only

the static person, but also the moving person, that the movement sensor can’t detect. It has been calibrated in Multi IR’s humidity and

temperature controlled facility.

The HET100 detector supports multiple communication modes, such as RS485, WiFi, ZigBee, 433, LoRa, by which the detector is

connected to the cloud platform easily. It can be used as the human presence sensors of the IoT system, for example smart home

system, smart building system. When the HET100 detects persons are present in the room, the IoT system will automatically drive the

corresponding linkage facility, like opening the air conditioner and light. On the contrary, the IoT system will automatically close the

linkage facilities, and change into security mode.
